Rexrothi hüdrauliline kolbpump
Muutuva töömahuga hüdrauliline kolbpump Rexroth 31/32 seeria A10V A10vo A10vso 18 28 45 71 100 140
Kõik HYLEMANi tooted on originaaliga täiesti samaväärsed ja vahetatavad.
Omadused
1. Muutuv pump koos aksiaalse kolvi pöörleva rühmaga plaadikonstruktsioonis avatud ahelaga hüdrostaatiliste ajamite jaoks.
2. Vooluhulk on võrdeline ajami kiiruse ja nihkega.
3. Vooluhulka saab lõpmatuseni muuta, reguleerides pesuplaadi nurka.
4. 2 äravooluava
5. Suurepärane imemisjõudlus
6. Madal müratase
7. Pikk kasutusiga
8. Soodne võimsuse ja kaalu suhe
9. Mitmekülgne kontrollerite valik
11. Lühike kontrollaeg
12. Läbiv ajam sobib hammasrataspumpade ja aksiaalkolbpumpade lisamiseks kuni sama suuruseni, st 100% läbiva ajamiga.
13. Sobib kasutamiseks mineraalõli ja HF hüdraulikavedelikega.
Detailsed pildid
Mudeli kirjeldus
A10VSO 30 31 52 53 seeria A10VO18, A10VO28, A10VO45, A10VO71, A10VO100, A10VO140 Rexroth hüdrauliline kolbpump
| Sisestage kood | |||||||||||||||||||||||||
| Sisestage kood | |||||||||||||||||||||||||
| 01 02 03 04 05 06 07 08 09 10 11 12 13 | |||||||||||||||||||||||||
| A10V(S) | O | / | 31 | - | V | ||||||||||||||||||||
| Versioon 18 28 45 71 88 100 140 | |||||||||||||||||||||||||
| 1 | Standardversioon (ilma koodita) | ||||||||||||||||||||||||
| Kiire versioon (välised mõõtmed on samad, mis standardversioonil) | - | - | - | H | |||||||||||||||||||||
| Aksiaalne kolviüksus | |||||||||||||||||||||||||
| 2 | Swashplate disain, muudetav, nimirõhk 280 bar, maksimaalne rõhk 350 bar | - | - | - | - | - | - | A10VS | |||||||||||||||||
| - | A10V | ||||||||||||||||||||||||
| Töörežiim | |||||||||||||||||||||||||
| 3 | Pump, avatud vooluring | O | |||||||||||||||||||||||
| Suurus (NG) | |||||||||||||||||||||||||
| 4 | Geomeetriline nihe, vt väärtuste tabelit lk 6 ja 7 | 18 | 28 | 45 | 71 | 88 | 100 | 140 | |||||||||||||||||
| Juhtseade | |||||||||||||||||||||||||
| 5 | Kahe punkti juhtimine, otsejuhtimine | DG | |||||||||||||||||||||||
| Hüdrauliline rõhuregulaator | DR | ||||||||||||||||||||||||
| vooluregulaatori hüdraulikaga | XT avatud | DFR | |||||||||||||||||||||||
| XT ühendatud loputusfunktsiooniga | DFR1 | ||||||||||||||||||||||||
| XT ühendatud ilma loputusfunktsioonita | DRSC | ||||||||||||||||||||||||
| voolu- ja diferentsiaalrõhu reguleerimisega, elektriliselt muudetav | EF1) | ||||||||||||||||||||||||
| rõhu väljalülitamisega | hüdrauliline kaugjuhtimispult | DRG | |||||||||||||||||||||||
| elektriline negatiivne juhtimine | U = 12 V | ED71 | |||||||||||||||||||||||
| U = 24 V | ED72 | ||||||||||||||||||||||||
| elektriline positiivne kontroll | U = 12 V | ER71 | |||||||||||||||||||||||
| U = 24 V | ER72 | ||||||||||||||||||||||||
| Surve-voolu võimsuse juhtimine | - | DFLR | |||||||||||||||||||||||
| seeria | |||||||||||||||||||||||||
| 6 | 3. seeria, register 1 | 31 | |||||||||||||||||||||||
| Pöörlemissuund | |||||||||||||||||||||||||
| 7 | Vaadatuna veovõlli pealt | päripäeva | R | ||||||||||||||||||||||
| vastupäeva | L | ||||||||||||||||||||||||
| Tihendusmaterjal | |||||||||||||||||||||||||
| 8 | FKM (fluoroelastomeer) | V | |||||||||||||||||||||||
| Veovõll 18 28 45 71 88 100 140 | |||||||||||||||||||||||||
| 9 | Splintvõll ANSI B92.1a | standardne võll | S | ||||||||||||||||||||||
| sarnane võlliga "S", kuid suurema sisendpöördemomendi jaoks | - | - | R | ||||||||||||||||||||||
| vähendatud läbimõõt, piiratud sobivus läbisõiduks (vt väärtuste tabelit lk 9) | ○ | U | |||||||||||||||||||||||
| sama mis "U", suurem pöördemoment; piiratud sobivus läbisõiduks (vt väärtuste tabelit lk 9) | - | W | |||||||||||||||||||||||
| Kinnitusäärik | |||||||||||||||||||||||||
| 10 | ISO 3019-1 (SAE) | 2-auk | C | ||||||||||||||||||||||
| 4-auk | - | - | - | - | - | - | D | ||||||||||||||||||
| 1) Vaata andmelehte 92709 | |||||||||||||||||||||||||
| Sisestage kood | |||||||||||||||||||||||
| 01 02 03 04 05 06 07 08 09 10 11 12 13 | |||||||||||||||||||||||
| A10V(S) | O | / | 31 | - | V | ||||||||||||||||||
| Tööport 18 28 45 71 88 100 140 | |||||||||||||||||||||||
| 11 | SAE ääriku pordid vastavalt J518 | Kinnitusniit | mitte läbisõiduks | - | - | - | 11 | ||||||||||||||||
| Töötavad pordid | meetriline; tagumine | - | - | - | - | - | 41 | ||||||||||||||||
| meetriline | Kinnitusniit | läbisõiduks | - | - | 12 | ||||||||||||||||||
| meetriline; külgmine ülemine alumine osa | - | - | - | - | - | 42 | |||||||||||||||||
| SAE ääriku pordid vastavalt J518 | Kinnitusniit | mitte läbisõiduks | - | - | - | 61 | |||||||||||||||||
| Töötavad pordid | UNF; tagumine | - | - | - | - | - | 91 | ||||||||||||||||
| UNF | Kinnitusniit | läbisõiduks | - | - | 62 | ||||||||||||||||||
| UNF; külgmine ülemine alumine osa | - | - | - | - | - | 92 | |||||||||||||||||
| Läbiv ajam (paigaldusvõimaluste kohta vt lk 53) | |||||||||||||||||||||||
| 12 | Äärik ISO 3019-1 Rumm splitsvõllile2) | 18 28 45 71 88 100 140 | |||||||||||||||||||||
| Läbimõõt Läbimõõt | |||||||||||||||||||||||
| ilma läbisõiduta | N00 | ||||||||||||||||||||||
| 82-2 (A) | 5/8 9T 16/32DP-s | K01 | |||||||||||||||||||||
| 3/4 11T 16/32DP-s | K52 | ||||||||||||||||||||||
| 101-2 (B) | 7/8 13T 16/32DP-s | - | K68 | ||||||||||||||||||||
| 1 in 15T 16/32DP | - | - | K04 | ||||||||||||||||||||
| 127-2 (C) | 1 1/4 in 14T 12/24DP | - | - | - | K07 | ||||||||||||||||||
| 1 1/2 17T 12/24DP | - | - | - | - | - | K24 | |||||||||||||||||
| 152-4 (D) 1 3/4 13T 8/16DP | - | - | - | - | - | - | K174) | ||||||||||||||||
| Solenoidide pistikud3) | |||||||||||||||||||||||
| 13 | Ilma pistikuta (ilma solenoidita, ainult hüdraulika juhtimisega, ilma koodita) | ||||||||||||||||||||||
| DEUTSCH – vormitud pistik, 2-pin, ilma summutusdioodita | P | ||||||||||||||||||||||
| = Saadaval ○=Soovi korral -=Pole saadaval | |||||||||||||||||||||||
| Märkus | |||||||||||||||||||||||
| Pange tähele projekti planeerimise märkusi lk 59. | |||||||||||||||||||||||
| Tellimuse vormistamisel palume täpsustada lisaks tüübikoodile ka asjakohased tehnilised andmed. | |||||||||||||||||||||||
| A10VSO 18 seeria | |
| A10VSO18DR/31R-PPA12N00 | A10VSO18DFLR/31R-PPA12N00 |
| A10VSO18DR/31R-PPA12K01 | A10VSO18DG/31R-PPA12N00 |
| A10VSO18DFR1/31R-PPA12N00 | A10VSO18DRG/31R-PPA12N00 |
| A10VSO18DFR1/31R-PPA12N00 | A10VSO18DFE1/31R-PPA12N00 |
| A10VSO18DFR1/31R-PPA12K01 | A10VSO18FHD/31R-PPA12N00 |
| A10VSO18DFR/31R-PPA12N00 | A10VSO18ED/31R-PPA12N00 |
| A10VSO 28 seeria | |
| A10VSO28DR/31R-PPA12N00 | A10VSO28DFLR/31R-PPA12N00 |
| A10VSO28DR/31R-PPA12K01 | A10VSO28DG/31R-PPA12N00 |
| A10VSO28DFR1/31R-PPA12N00 | A10VSO28DRG/31R-PPA12N00 |
| A10VSO28DFR1/31R-PPA12N00 | A10VSO28DFE1/31R-PPA12N00 |
| A10VSO28DFR1/31R-PPA12K01 | A10VSO28FHD/31R-PPA12N00 |
| A10VSO28DFR/31R-PPA12N00 | A10VSO28ED/31R-PPA12N00 |
| A10VSO 45 seeria | |
| A10VSO45DR/31R-PPA12N00 | A10VSO45DFR/31R-PPA12K26 |
| A10VSO45DR/31R-PPA12K01 | A10VSO45DFLR/31R-PPA12N00 |
| A10VSO45DFR1/31R-PPA12N00 | A10VSO45DG/31R-PPA12N00 |
| A10VSO45DFR1/31R-PPA12N00 | A10VSO45DRG/31R-PPA12N00 |
| A10VSO45DFR1/31R-PPA12K02 | A10VSO45DFE1/31R-PPA12N00 |
| A10VSO45DFR/31R-PPA12N00 | A10VSO45FHD/31R-PPA12N00 |
| A10VSO45DFR/31R-PPA12K01 | A10VSO45ED/31R-PPA12N00 |
| A10VSO 71 seeria | |
| A10VSO71DR/31R-PPA12N00 | A10VSO71DFR/31R-PPA12K27 |
| A10VSO71DR/31R-PPA12K01 | A10VSO71DFLR/31R-PPA12N00 |
| A10VSO71DFR1/31R-PPA12N00 | A10VSO71DG/31R-PPA12N00 |
| A10VSO71DFR1/31R-PPA12N00 | A10VSO71DRG/31R-PPA12N00 |
| A10VSO71DFR1/31R-PPA12K02 | A10VSO71DFE1/31R-PPA12N00 |
| A10VSO71DFR/31R-PPA12N00 | A10VSO71FHD/31R-PPA12N00 |
| A10VSO71ED/31R-PPA12N00 | |
A10VSO 100 seeria:, A10VSO100DR/31R-PPA12N00, A10VSO100DR/31R-PPA12K01, A10VSO100DFR1/31R-PPA12N 00, A10VSO100DFR1/31R-PPA12N00,, A10VSO100DFR1/31R-PPA12K01 A10VSO100DFR/31R-PPA12N{{101} },, A10VSO100DFLR/31R-PPA12N00, A10VSO100DG/31R-PPA12N00,, A10VSO100DRG/31R-PPA12N{ {330}}, A10VSO100DFE1/31R-PPA12N00,, A10VSO100DFE1/31R-PPA12K02, A10VSO100FHD/31R-{4PPA11}{ } R902405606 A10VO100DFR1/31R-VSC62N00, R902411500 A10VSO45DFLR/31R-VPA12N00 145N R9024214086-81 R902429793 A10VSO140DFLR / 31R-VPB12N 8, R902459592 A10VSO140DFR1/31R-VPB12K68 R902460463 A10VSO1 00DFLR/31R-VPA12N00 140N, R902460861 A10VO45DFR1/31L-VSC62K68 R902460920 A10VSO28DFLR/31R-VPA12N{160}}N,1099902 12N00 50N R902460922 A10VSO45DFLR /31R-VPA12N00 100N, R902460923 A10VSO71DFLR/31R-VPA12N00 156N R902460924 A10VSO71DFLR/31R-VPA12N00 240N, R9025124{6} -VPA12N{{ 195}}N R902460926 A10VSO100DFLR/31R-VPA12N00 200N, R902460927 A10VSO100DFLR/31R-VPA12N00 245N R90248241/6N R9048241 31R-VPB12N 2K68 R902461113 A10VO28DFR1/31L-VSC62K01, R902461114 A10VO28DFR1 /31L-VSC62N00 R902461115 A10VO45DFR1/31R-VSC62K68, R902461116 A10VO71DFR1/31R-VSC62K01 R902461117 R902461117 A10VO71N 1228 A10VSO45DFR1/31R-VPA12K68 R902461229 A10VSO71DFR1/31R-VPA12K68, R902461230 A10VSO1{ {585}}DFR1/31R-VPA12K68 R910903160 A10VSO28DFR/31R-PPA12N00, R910903163 A10VSO28DR/31R-PPA12N00 R91}{6106 31R-PSC62N{ 620 907404 A10VO45DFR/31R- PSC62K01, R910907918 A10VO45DFR1/31R-PSC62K04 R910907919 A10VSO28DR/31R-PPA12K01, R910908655 A10VO28DFR/31R-PSC9251D R-PPA12N00, R910909288 A10VO45DFR1/31L-PSC62N00 R910909613 A10VSO45DFR/31R-PPA12K01 , R910909949 A10VO45DFR/31L-PSC62K01 R910910181 A10VO45DFR1/31R-PSC62N00, R910910590 A10VSO28DFR1/31R-PPA1921} A DFR/31R-PPA12K26, R910911737 A10VO28DFR1/31R-PSC61N00 R910912{ {691}}7 A10VSO100DR/31R-PPA12N00, R910915421 A10VO28DR/31R-PSC62K01 R910916472 A10VO45DFR1/31L-PSC62101FR -PSC62K01 R910920557 A10VO45DFR1/31R-PSC62K02, R910921546 A10VSO140DFR1 /31R-PPB12N00 R910922744 A10VSO100DFR1/31R-PPA12N00, R910922947 A10VO28DFR1/31L-PSC62K01 R98VSO1 734}}, R910923181 A10VO28DFR1/31R- PSC62K01 R910926318 A10VSO28DFR1/31R-PPA12K01, R910927068 A10VSO45DFR1/31R-PPA12K02 R910927083 A10VSO1{74127083 A10VSO1{741}1K01, R21 0VSO140DFR1/31R-PPB12K02 R910932852 A10VSO140DRG/31R-PPB12N00, R910934823 A10VSO1{{756 }}DFLR/31R-PPA12N00 R910935974 A10VSO140DFLR/31R-PPB12N00, R910935975 A10VSO45DFLR/31R-PPA12N00 R910935974} R60935974 2N00, R910936062 A10VSO28DFLR/ 31R-PPA12N00 R910936094 A10VSO140DFLR/31R-PPB12N{{800}, R910936130 A10VSO28DFLR/31R-PPA12N31 A3 1R-PPA12N{{ 829}}, R910936473 A10VSO100DFLR/31R-PPA12N00 R910936738 A10VSO100DFLR/31R-PPA12N00, R93936473 A10VSO1 866}} R910936790 A10VSO100DFLR/31R-PPA12N00, R910936910 A10VSO45DFLR/31R-PPA12N00 R910936912 A10VSORD1} 804 A10VSO18DFR1/31R-PUC62N{{926 }} R910938977 A10VSO140DFLR/31R-PPB12N00, R910939026 A10VSO28DFLR/31R-PPA12N00 R910939120 A10VO71{-DFRC/6}2}2} R910939183 A10VSO45DFR/31R-PPA12N00 R910939192 A10VSO140DFR/31R-PPB12N00, R910939643 A10VSO1{{970}N-9PP{101} {985}}45 A10VO1{{ 992}}DFR1/31L-PSC62N00, R910940520 A10VSO18DFR/31R-PPA12N{{1{1011}}4}} R910940582 A10VSO45DFLR/39} 8DFR/31L-PSC62N{ {1035}} R910940936 A10VSO28DFLR/31R-PPA12N00, R910941109 A10VSO140DFLR/31R-PPB12N00 R910941657 R910941657 R910941657 A11/7VO 10942503 A10VSO18DR/31R-PPA12N{1061}} R910942635 A10VSO71DFR / 31R-PPA12N A10VO45DFR1/31R-PSC61N00 R910943468 A10VSO1{{ 1095}}DFLR/31R-PPA12N00, R910943655 A10VO45DFR/31R-PSC62N00 R910943841 A10VSO140DFLR/31R-PPB12N{} 21}}DFLR/31R-PPA12N{ {1128}} R910944067 A10VSO71DFLR/31R-PPA12N00, R910944195 A10VO71DFR1/31L-PSC62N00 R910944440 R910944440 A10PPA15}, 10944502 A10VSO71DFLR/31R-PPA12N00 R910944730 A10VSO71DFLR/31R-PPA12N00, R910945133 A10VSO71DR/31R-PPA12N00 R910945178 A10VSO18DFR18DFR1/317N{1183}} A10VO71DFR1/31R-PSC61N00 R910946188 A10VO71DFR/31L -PSC62N00, R910946661 A10VO71DFR1/31L-PSC62K01 R910947666 A10VSO18DFR/31L-PSC62N00, R910947870 A10VO71DFR1/31L-PSC62K01 72 A10VSO71DFR1/31R-PPA12K02 .R910948654 A10VSO71DFLR/31R-PPA12N00 R910948790 A10VSO71DFLR/31R-PPA12N00, R910961216 A10VSO71DFLR/31R-PPA12N00 R910970014 A10VSO71DFLR/31R-PPA12N00 974886 A10VO60DFR1/52R-PSD61N{{1267 }} R910988126 A10VSO10DR/52R-PKC64N00, R910988128 A10VSO10DFR1/52R-PKC64N00 R910990406 A10VSO10DR/52R{10VSO10.9.90} 87 A10VSO10DFR1/52R-PPA14N00 A10VSO18DFR1/ 30 -PPA12N00, A10VSO18DFR1/31R-PPB12NOO A10VS018DFR1/31R-PPB12NOO, A10VSO18DR/31R-PPA12N00, A10VSO28DFR1/31R-121R18 -PPA12N00 A10VO28DR/31R-PSC12N PPA12N00 A10VSO28DFR/31R-PSA12N00, A10VO28DFR1/31L-PSC62N00, A10VO28DFR1/31R-PSC62N00 A10VS045DR/31R-PPA12N00, A10VSO45DR/31R-PPA12N00, A10VS045R-PPA12N00, A10VS045DFRP1/5211R PA12N00, A10VSO45DFR1/31R-PPA12N00, A10VO45DFR1/31R-PSC62K02 A10VSO45DFR1/32R-PPB12N00 , A10VSO71DFR1/31R-PPA12N00, A10VS071DFR1/31R-PPA12N00 A10VSO71DFR1/31R-PPA12KB5, A10VSO71DFR/31R-PSC62K07, A10VSO71/31R-PPA12N01 /31R-PPA12N00, A1OVSO71DFR1/31R-PPA12N00, A1OVS071DFR1/31R-PPA12N00 A10VSO71DFR1/31R- PPA12N00, A10VSO71DFR1/32R-VPB22U99, A10VSO71DFR1/31R-PPB12NOO EA10VSO71DR/31R-PPA12N00, A10VSO71DR/31R-PPA12VSO1N, A0DR101000 0DR/31R-PPA12N00, A10VSO100DR/31R-VPA12N00, A10VS0100DR/31R-VPA12N00 A10VSO100DFR1/31R -PPA12N00, A10VS0100DFR1/31R-PPA12N00, A10VSO100DR/31R-PPA12N00 A10VSO100DFR1/31R-VPB12N00, A10VS0100DFR1/31R-PPA12N00, A10VS0100DFR1/31R-PPA12N00 00 A10V0100DR/31R-PSC11N00, A10VS0100DR/31R-PTA12N00, A10VSO140D/31R-PPB12N00 A10VSO140DR/ 31R-PPB12N00, A10VS0140DR/31R-PPB12N00, E-A10VSO140DFR1/31R-PPA12N00 A10VSO140DFR1S/31R-PPB12N00, A10VSO140DFR01,10VSO140DFR01/01 -PPB12N00 A10VSO140DR/31R-PPB12N00, A10VS0140DR/31R-PPB12NOO, A10VSO140DR/31R- VPB12N00 A10VSO140DR/31R-VPB22U99, A10VSO140DFR1/31R-PPB12N00
